ball valve / Up to 6000 psi (413bar)/metric and fractional tube fittings,NPT threads, ISO/BSP threads, weld endsmanual / Size: 1/16 to 3/4 in., 3 to 22 mm/shut-off / TB series
Athena Trunnion Ball Valve
-Material: 316SS, titanium, other material as request
-Working Temperature -65℉ to 450℉（- 53℃ to 232℃）
-Working Pressure: Up to 6000 psi (413bar)
-Valve Seat: PTFE, RPTFE, UHMWPE
-Flow Way: Straight and 3-way available
-End Connection Type: Metric and fractional tube fittings,NPT threads, ISO/BSP threads, weld ends
-End Connection Size: 1/16 to 3/4 in., 3 to 22 mm
-Working Temperature -65℉ to 450℉（- 53℃ to 232℃）
-Working Pressure: Up to 6000 psi (413bar)
-Valve Seat: PTFE, RPTFE, UHMWPE
-Flow Way: Straight and 3-way available
-End Connection Type: Metric and fractional tube fittings,NPT threads, ISO/BSP threads, weld ends
-End Connection Size: 1/16 to 3/4 in., 3 to 22 mm
Quantity
Athena Trunnion Ball Valve
Performance
-Compact design, with strong flow capability
-V-type packing: better seal, ware-resistance,lower torque force
-Variety of end connection type available
