1/2”-2” 150LB~1500LB Provides Flow Control Suitable For High Pressure And Temperature
Bellows Sealed Globe Valve
Size:1/2”~2”

Pressure rating: 150Lb~1500Lb

Material: Carbon steel /Stainless steel / Alloy steel /Special ( Monel /Inconel /Hastelloy etc.)/alloy steel/ Al-bronze

End connection: RF/RTJ/BW/SW/FNPT

Construction: Bolted Bonnet, Welded Bonnet, Pressure Seal

Operation: Hand wheel/ Gear/Motor/Pneumatic actuators

Bore: Full Bore and Reduced Bore

NACE: MR0175

Bore: Full Bore and Reduced Bore

Certificate: CE/PED, ISO, ATEX, SIL
Quantity

Product Overview:

Athena Bellows sealed globe valves
- Have enhanced outer sealing capability when compared to standard globe valves.
- Stainless steel bellow prevents any external leakage.
- There is also a stuffing box as a secondary sealing around the valve stem, which should eliminate leakage to atmosphere for a limited period.
- Employed in piping systems to safeguard against leakage.
- When selected and installed properly, they minimize the risk of potentially harmful chemicals causing injury or illness to workers and damage to the surrounding environment.

For all the valves,  material test certificates, hydraulic test certificates & MTC 3.1 will be provided. And, third party inspection can be conducted based on client's request.


Partial List of Applications:

- Oil & Gas Pipelines
- Refineries and Petrochemical Plants
- Power Generation
- Gas and Coal Fired Turbines
- District Heating
- Gas Measurement Systems
- Offshore Platforms
- HIPPS Systems
- Cryogenic Service Applications
- Emergency Shut Down Valves
- Pulp & Paper
- Mining
- Boiler Steam and Drain Applications
